Electrocorp Laser Cutting, Laser Engraving Fume Extractor

  • Ideal for Laser engraving, laser cutting
  • Tested and refined to resist clogging, this unit features a 0.5 micron pre-filer to capture larger particulate matter, a medical grade HEPA filter to remove 99.97% of 0.3 micron particulate matter and a large 24 lb. carbon filter to adsorb volatile organic compounds, gases and smoke odor. A 6" flange for ducting is also included.

Fume Extractor, Air Filtration System, Air Cleaner, Air Scrubber for Laser Engraving, Laser marking, Laser Cutting

Dust, Particles, Smoke, Odor, Chemical Fumes

Affordable air filtration systems, air cleaners, scrubbers for laser engraving engineered to remove chemical vapors, laser cutting fumes and fine particles while preventing the constant clogging that has plagued other laser air cleaning systems in the past. Powerful source capture units remove airborne pollutants before they become airborne and circulate. This capture method offers superior protection for operators, helps to prevent product contamination and safeguards your sensitive laser optics.



Ideal for:



  • Laser engraving fumes
  • Laser cutting smoke
  • Odor control
  • Fine particles



Features, Benefits, Advantage:



  • Lower capital and operating costs
  • Source-capture for precision air cleaning
  • Deeper carbon beds for better adsorption of laser engraving vapors, chemicals and odors
  • Custom carbon blends offered for specific materials, such as laser engraving on PVC
  • Refillable, reusable carbon canisters
  • Superior particle filtration
  • Separate filters for particles and chemicals/vapors/odors
  • Dual layer, easy access pre-filter prologues the life of the HEPA filter
  • Adjustable airflow
  • Robust metal housing
  • Tested and approved by leading manufacturers including Universal Laser Systems and Epilog.

Laser 6000 (aka Laser LX)

Tested and refined to resist clogging, this unit features a 0.5 micron pre-filer to capture larger particulate matter, a medical grade HEPA filter to remove 99.97% of 0.3 micron particulate matter and a large 24 lb. carbon filter to adsorb volatile organic compounds, gases and smoke odor. A 6" flange for ducting is also included.

Technical Characteristics

Dimensions:

Shipping Weight:

Filtration System:

Carbon Filter:

CFM:

Available Colors: Black

27" x 15 " x 40" Includes 6" Flange

58 lbs. (2 boxes)

MAC-B Carbon, HEPA, Special Inlet Pre-filter: 30 PPI Foam for heavy particles and 0.3 micron electrostatic to protect the Medical Grade HEPA

24 lbs

735 (free flow)

Electrocorp RSU 12 CCR - 350 CFM - (Activated Charcoal / Carbon Filter - Reverse Flow)

Technical Characteristics

Dimensions:

Operating Weight:

Filtration System:

Carbon Filter:

CFM:

Decibels:

Maneuverability:

23" X 18"

55 lbs.

Blue tacky 10 micron pre-filter, carbon filter, insert of 99% electrostatic and a 30 ppi foam gasket

23 lbs.

350

44-62 dB

5 x 2" diameter wheels

Electrocorp RSU 12 CCR - 350 CFM - (Activated Charcoal / Carbon Filter - Reverse Flow)

Price List

RSU 20 CCHR - 450 CFM - (Activated Charcoal / Carbon Filter + HEPA filter - Reverse Flow)

Technical Characteristics

Dimensions:

Operating Weight:

Filtration System:

Carbon Filter:

CFM:

Decibels:

Maneuverability:

31" x 18"

84 lbs.

Blue tacky 10 micron pre-filter, carbon filter, insert of 99% electrostatic and a 30 ppi foam gasket

34 lbs

450

48-66 dB

5 x 2" diameter wheels

RSU 20 CCHR - 450 CFM

Price List

Call 1-800-626-0664 for help with your product selection and / or help with placing your order

* Free Ground, Standard  Shipping to the Continental US and Canada / Specs & Prices subject to change without prior notice | Call to order your replacement filters
